- Scale:1/10th
- Brushed/Brushless:BL
- Sensored/Sensorless:SD FOC
- Waterproof:YES(IP67)
- Applications:1/10thRock Crawler
- Cont./Peak Current:60A/360A
- Input Voltage:2-3S Lipo/6-9 Cell NiMH
- Website:www.lxrcmodel.com
- Use:Vehicles & Remote Control Toys
- Place of Origin:CN;GUA
- Brand Name:Hobbywing
- Model Number:AXE550KV-2700kv-FOC/AXE550KV-3300kv-FOC
Hobbywing Xerun 2700kV AXE550 FOC sensored Brushless Power System Motor & ESC combo for Rc 1/10 Climbing Car
What is the Details of our Product?
Features
FOC (Field-oriented Control) for Super Linearity & High
Torque & Extreme Slience
New sensor technology has changed the feel, performance, and overall tune-ability of the new Axe ESC and Motor in ways some
have never experienced. Field-oriented Control is the name of this new tech, and is something all new to the scale trail, rock racing,
and rc world in-general. This new style of sensor allows extremely accurate control and sensing of the motor while maintaining
extreme performance and reliability. The motor and ESC are able to match the RPM of the motor to your throttle position under all
driving conditions. This greatly improves down hill driving giving this system the ability to drive down hill under complete control.
Torque & Extreme Slience
New sensor technology has changed the feel, performance, and overall tune-ability of the new Axe ESC and Motor in ways some
have never experienced. Field-oriented Control is the name of this new tech, and is something all new to the scale trail, rock racing,
and rc world in-general. This new style of sensor allows extremely accurate control and sensing of the motor while maintaining
extreme performance and reliability. The motor and ESC are able to match the RPM of the motor to your throttle position under all
driving conditions. This greatly improves down hill driving giving this system the ability to drive down hill under complete control.
Product Details
Product Name:XeRun Axe Brushless Power System
Type
Scale:1/10th
Brushed/Brushless:BL
Sensored/Sensorless:SD FOC
Waterproof:YES(IP67)
Applications:1/10thRock Crawler
Specifications
Cont./Peak Current:60A/360A
Input Voltage:2-3S Lipo/6-9 Cell NiMH
BEC Output:Switch Mode:6V/7.4V@3A
Wires & Connectors
Input Wires:Red-14AWG-200mm*1/ Black-14AWG-200mm*1
Output Wires:No
Input Connectors:XT60
Output Connectors:Solder Posts
ESC Programing via
SET Button on ESC:Not Supported
LED Program Box:Not Supported
LCD Program Box:Not Supported
WiFi Module:Not Supported
Bluetooth Connection:Supported
Firmware
Firmware Upgrade:Supported
Size:47.4x36.2x24.6mm
Weight:82g
Type
Scale:1/10th
Brushed/Brushless:BL
Sensored/Sensorless:SD FOC
Waterproof:YES(IP67)
Applications:1/10thRock Crawler
Specifications
Cont./Peak Current:60A/360A
Input Voltage:2-3S Lipo/6-9 Cell NiMH
BEC Output:Switch Mode:6V/7.4V@3A
Wires & Connectors
Input Wires:Red-14AWG-200mm*1/ Black-14AWG-200mm*1
Output Wires:No
Input Connectors:XT60
Output Connectors:Solder Posts
ESC Programing via
SET Button on ESC:Not Supported
LED Program Box:Not Supported
LCD Program Box:Not Supported
WiFi Module:Not Supported
Bluetooth Connection:Supported
Firmware
Firmware Upgrade:Supported
Size:47.4x36.2x24.6mm
Weight:82g
Product Picture
Product Pictures
Item Packing
Hobbywing Xerun AXE550 FOC sensored Brushless Power System Motor & ESC combo x 1
You can visit our wholesale online shop: www.lxrcmodel.com.
Regarding to the shipment, We can ship by EMS, Fedex, DHL, UPS, Air Mail, Sea.
Regarding to the payment, We can accept pay by Paypal, Western Union, Bank Transfer
We have not any MOQ for our customers
